TASK 71-52-42-300-003 Fire Detection (System B) Harness - Replace The Connectors, Repair-003 (VRS2983)

DMC:V2500-A0-71-52-4200-02A-920A-C|Issue No:002.00|Issue Date:2018-11-01

Export Control

EAR Export Classification: Not subject to the EAR per 15 C.F.R. Chapter 1, Part 734.3(b)(3), except for the following Service Bulletins which are currently published as EAR Export Classification 9E991: SBE70-0992, SBE72-0483, SBE72-0580, SBE72-0588, SBE72-0640, SBE73-0209, SBE80-0024 and SBE80-0025.

Copyright

© IAE International Aero Engines AG (2001, 2014 - 2021) The information contained in this document is the property of © IAE International Aero Engines AG and may not be copied or used for any purpose other than that for which it is supplied without the express written authority of © IAE International Aero Engines AG. (This does not preclude use by engine and aircraft operators for normal instructional, maintenance or overhaul purposes.).

Applicability

All

Common Information

TASK 71-52-42-300-003 Fire Detection (System B) Harness - Replace The Connectors, Repair-003 (VRS2983)

Effectivity

FIG/ITEM

PART NO.

01-005

740-5862-501

01-005

740-5862-503

01-005

740-5862-505

01-005

740-5862-507

01-005

745-5862-501

01-005

745-5862-503

01-005

745-5862-505

01-005

745-5862-901

General

This repair can be done on the harnesses during overhaul, while they are installed on the engine.

To identify the consumable materials refer to the PCI.

The Part No. identified with (*) will have 89 before it. The Part No. identified with (**) will have 380AS00 before it.

Repair parts

FIG/ITEM

PART NO.

PART IDENT

QTY

01-100

**3M1204A2

Backshell

AR

01-100

387AS008M1204A2

Backshell

AR

01-100

387AH008M1204A2

Backshell

AR

01-100

ESC77E14

Backshell

AR

01-150

*2-26K-14S-5SN

Connector

AR

01-150

MS3459KS14S5S

Connector

AR

01-200

**3M1204A2

Backshell

AR

01-200

387AS008M1204A2

Backshell

AR

01-250

E0442SE12-03PN

Connector

AR

Repair part location - Refer to Figure.

Preliminary Requirements

Pre-Conditions

NONE

Support Equipment

NameManufacturerPart Number / IdentificationQuantityRemark
Strap WrenchLOCALStrap Wrench

TG-70 or BT-BS-611

Torque Wrench - 0 to 1000 lbf.in rangeLOCALTorque Wrench
Extractor/inserter toolLOCALExtractor/inserter tool

16g or 20g

Consumables, Materials and Expendables

NameManufacturerPart Number / IdentificationQuantityRemark
CoMat 02-127 LOCKWIRELOCALCoMat 02-127
CoMat 02-138 LOCKWIRELOCALCoMat 02-138
CoMat 02-141 LOCKWIRELOCALCoMat 02-141
CoMat 06-153 FELT TIP MARKER, RAPID DRYINGLOCALCoMat 06-153
CoMat 08-026 THREADLOCKING MATERIALLOCALCoMat 08-026

Spares

NONE

Safety Requirements

NONE

Procedure

    1. SUBTASK 71-52-42-350-053 Disassemble the Connector Assembly

      WARNING

      PUT ON PROTECTIVE GOGGLES WHEN YOU CUT THE LOCKWIRE. PIECES OF THE LOCKWIRE CAN CAUSE DAMAGE TO YOUR EYES.

    1. Refer to Figure.

      2. Cut and remove the lockwire from the screws, the coupling nut and the shell.

      1. Be careful not to cause damage to the lockwire holes.

      3. If the backshell is not a straight type, make a mark on the shell which aligns with the master keyway.

    4. Remove the screws and the strain-relief clamp from the coupling nut.

      5. Remove the coupling nut from the shell.

      1. Use the applicable Strap Wrench (BTBS- 611 or TG-70).

      2. Move the coupling nut and the grounding ferrule away from the shell.

      3. Be careful not to cause damage to the ground-shields of the cables.

      6. Remove the shell from the connector.

      1. Use the applicable Strap Wrench (BTBS- 611 or TG-70).

      2. Move the shell away from the connector.

      3. Be careful not to cause damage to the ground-shields of the cables.

    2. SUBTASK 71-52-42-350-054 Remove the Contacts from the Connector

    1. Refer to Figure.

      2. Attach a temporary identification tag to each of the cables in the connector.

      1. Write on the tag the number of the connector hole from which the cable came.

      3. Remove a contact from the connector.

      1. Use the applicable Extractor/inserter tool l (16g or 20g).

      2. Put the cable in the groove of the tool.

      3. Push the tool along the cable and in to the rear of the connector, until it touches the contact (the tool will open the collet).

      4. Hold the cable and the tool together and remove the contact from the rear of the connector.

      4. Remove the remaining contacts from the connector.

      1. Do Step again, for the remaining contacts.

    3. SUBTASK 71-52-42-350-056 Remove the Components of the Connector Assembly

      1. Remove the shell, the grounding ferrule and the coupling nut, from the harness.

      1. Be careful not to cause damage to the contacts or the ground-shields .

    4. SUBTASK 71-52-42-220-052 Examine the Components

      1. Examine the connector, the contacts, the coupling nut, the grounding ferrule, the screws and the shell.

      1. Refer to INSPECTION/CHECK-01 TASK 71-52-42-200-301.

      2. Reject the parts which are unserviceable.

    5. SUBTASK 71-52-42-350-057 Install the Replacement Components of the Connector Assembly

      CAUTION

      THE REPLACEMENT COMPONENTS MUST HAVE THE SAME PART NUMBERS AS THE COMPONENTS WHICH WERE REMOVED. INCORRECT COMPONENTS CAN CAUSE DAMAGE TO THE SYSTEM.

    1. Refer to Figure.

      2. Install the new, or serviceable, components to the harness.

      1. Install the components in the sequence that follows: the coupling nut, the grounding ferrule and the shell.

      2. Be careful not to cause damage to the contacts or the ground-shields.

    6. SUBTASK 71-52-42-350-058 Install the Contacts to the Connector

      CAUTION

      THE CONTACTS MUST BE INSTALLED IN THEIR CORRECT POSITIONS IN THE CONNECTOR. IF THEY ARE INSTALLED IN THE INCORRECT POSITIONS THE SYSTEM CAN BE DAMAGED.

    1. Refer to Figure.

      2. Find the contact which must be installed in the center hole of the connector.

      1. You must install the contacts at the center of the connector first and work out.

      3. Install the center contact to the connector.

      1. Use the applicable Extractor/inserter tool (16g or 20g).

      2. Put the cable in the groove of the tool.

      3. Push the tool along the cable, until it touches the flange of the contact.

      4. Hold the cable and the tool together and use the tool to push the contact in to the connector hole.

      5. When the contact is in the correct position, in the connector hole, release the cable and remove the tool.

      6. Lightly pull the cable to make sure that the contact is engaged correctly in the connector.

      4. Install the remaining contacts to the connector.

      1. Do Step again for the remaining contacts.

      2. Make sure the contacts are installed in the positions noted during their removal.

      3. Install the contacts nearest to the center first.

      5. Remove the identification tags from the cables.

      1. Remove the temporary tags, which were installed in Step.

    7. SUBTASK 71-52-42-350-059 Assemble the Connector Assembly

    1. Refer to Figure.

      2. Install the shell to the connector.

      1. Use the applicable Strap Wrench (BTBS- 611 or TG-70) to tighten the shell.

      2. If the backshell is not a straight type, align the mark (Step) with the master keyway.

      3. Install the coupling nut to the shell.

      1. Put the ground-shields an equal distance apart around the shell.

      2. Put the ground ferrule along the harness, until it touches the ground-shields.

      3. Put the ground-shields through the coupling nut.

      4. Put two drops of the CoMat 08-026 THREADLOCKING MATERIAL, opposite to each other on the threads of the shell.

      5. Install the coupling nut to the shell.

      6. Use the torque wrench and the applicable Strap Wrench (BT-BS-611 or TG-70), to torque the coupling nut to 10 lbf in. (1.13 Nm).

      4. Install the strain-relief clamp to the coupling nut.

      1. Make sure that all of the twists and bends are out of the cables.

      2. Attach the clamp to the coupling nut with the two screws.

      3. Use the torque wrench to torque the screws to between 10 lbf in. and 20 lbf in. (1.13 Nm and 2.26 Nm).

    8. SUBTASK 71-52-42-750-054 Do a Continuity and Insulation Test on the Connector Assembly

      1. Do a test for continuity and insulation.

      1. Refer to TESTING-01 TASK 71-52-42-700-301.

    9. SUBTASK 71-52-42-350-060 Safety the Connector Assembly

    1. Refer to Figure.

      2. Safety the connector assembly.

      2. Make sure that the shell, the coupling nut and the screws, are all safetied.

    10. SUBTASK 71-52-42-850-056 Put the Repair Scheme Number on the Harness

      1. Put the repair scheme number VRS2983 on the identification sleeve, of the harness, adjacent to the part number.

    11. Figure: Repair Details and Dimensions

    Repair Details and Dimensions

    Figure: Repair Details and Dimensions

    Repair Details and Dimensions

    Figure: Repair Details and Dimensions

    Repair Details and Dimensions

    Figure: Repair Details and Dimensions

    Repair Details and Dimensions
