TASK 72-32-17-300-004 No. 2 Bearing Support - Blend Repair, Repair-004 (VRS1210)

DMC:V2500-A0-72-32-1701-00A-649A-C|Issue No:002.00|Issue Date:2016-08-01

Export Control

EAR Export Classification: Not subject to the EAR per 15 C.F.R. Chapter 1, Part 734.3(b)(3), except for the following Service Bulletins which are currently published as EAR Export Classification 9E991: SBE70-0992, SBE72-0483, SBE72-0580, SBE72-0588, SBE72-0640, SBE73-0209, SBE80-0024 and SBE80-0025.

Copyright

© IAE International Aero Engines AG (2001, 2014 - 2021) The information contained in this document is the property of © IAE International Aero Engines AG and may not be copied or used for any purpose other than that for which it is supplied without the express written authority of © IAE International Aero Engines AG. (This does not preclude use by engine and aircraft operators for normal instructional, maintenance or overhaul purposes.).

Applicability

All

Common Information

TASK 72-32-17-300-004 No. 2 Bearing Support - Blend Repair, Repair-004 (VRS1210)

Effectivity

FIG/ITEM

PART NO.

01-850

5W2046

01-850

5W2253

Material of component

RR

DESCRIPTION

SYMBOL

MATERIAL

No. 2 bearing support assembly

6Al-4V Titanium

General

Price and availability - none

The practices and processes referred to in the procedure by the TASK number are in the SPM.

For the method to clean the parts, refer to TASK 72-32-17-100-000 (CLEANING-000).

Preliminary Requirements

Pre-Conditions

NONE

Support Equipment

NONE

Consumables, Materials and Expendables

NONE

Spares

NONE

Safety Requirements

NONE

Procedure

    1. SUBTASK 72-32-17-350-051 Blend Damaged Surface of the No. 2 Bearing Support Assembly (01-850)

    1. Refer to Figure.

      2. Blend damaged surface.

      1. Refer to the SPM TASK 70-35-03-300-501.

      2. If the damage can not be removed in accordance with blend limit, Figure. reject the No. 2 bearing support assembly.

    2. SUBTASK 72-32-17-350-052 Examine the No. 2 Bearing Support Assembly (01-850)

      1. Examine the repaired No. 2 bearing support assembly.

      1. Refer to TASK 72-32-17-200-000 (INSPECTION-000).

    3. Figure: Location on the No. 2 bearing support assembly

    Location on the No. 2 bearing support assembly

    Figure: Location on the No. 2 bearing support assembly

    Location on the No. 2 bearing support assembly

Requirements After Job Completion

Follow-On Conditions

NONE
Change Type:

Corrected the SPM Task number
