TASK 72-50-53-300-044 No. 5 Bearing Pressure Oil Tube - Blend Repair Surface Damage, Repair-044 (VRS3263)
General
Price and availability - refer to IAE.
The practices and processes referred to in the procedure by the TASK numbers are in the SPM.
Preliminary Requirements
Pre-Conditions
NONESupport Equipment
| Name | Manufacturer | Part Number / Identification | Quantity | Remark |
|---|---|---|---|---|
| Fine file | LOCAL | Fine file | ||
| Workshop Inspection Equipment | LOCAL | Workshop Inspection Equipment |
Consumables, Materials and Expendables
NONESpares
NONESafety Requirements
NONEProcedure
Refer to Figure and SPM TASK 70-35-21-350-501.
Blend damage to a maximum of 0.010 in (0.254 mm) in depth.
Blend high metal and surface damage on the tube.
SUBTASK 72-50-53-350-105 Blend High Metal and Surface Damage on the No. 5 Bearing Pressure Tube
Refer to Inspection - 000 TASK 72-50-53-200-100 .
Examine the tube after blend repair.
SUBTASK 72-50-53-220-193 Examine the Repair
Figure: Blend Repair the No. 5 Bearing Scavenge Tube
Blend Repair the No. 5 Bearing Scavenge Tube
