DMC:V2500-A1-71-52-44-05A-941A-DIssue No:001.00Issue Date:2014-05-01
Export Control
EAR Export Classification: Not subject to the EAR per 15 C.F.R. Chapter 1, Part 734.3(b)(3), except for the following Service Bulletins which are currently published as EAR Export Classification 9E991: SBE70-0992, SBE72-0483, SBE72-0580, SBE72-0588, SBE72-0640, SBE73-0209, SBE80-0024 and SBE80-0025.Copyright
© IAE International Aero Engines AG (2001, 2014 - 2021) The information contained in this document is the property of © IAE International Aero Engines AG and may not be copied or used for any purpose other than that for which it is supplied without the express written authority of © IAE International Aero Engines AG. (This does not preclude use by engine and aircraft operators for normal instructional, maintenance or overhaul purposes.).Applicability
All
| Fig. Item | Part No. | Description | Effect/Model Applic. | UPA |
|---|---|---|---|---|
| 05 | ||||
| B71524405 | ELECT HARNESS-LIGHT DUTY-EEC LINK HARNESS-CORE, PRE SBE75-0005 | aa | ||
| SBE0005-01 | ELECT HARNESS-LIGHT DUTY-EEC LINK HARNESS-CORE, PRE SBE71-0162 | ab | ||
| SBE0162-01 | ELECT HARNESS-LIGHT DUTY-EEC LINK HARNESS-CORE, PRE SBE72-0329 | ac | ||
| SBE0329-01 | ELECT HARNESS-LIGHT DUTY-EEC LINK HARNESS-CORE | ad | ||
| 950 | 6A3991 | • BRACKET - A/O POST SBE75-0005 PRE SBE71-0162 | ab-ad | 1 |
| 950A | 6A5907 | • BRACKET - A/O POST SBE71-0162 | ab-ad | 1 |
| 952 | AS20907 | • BOLT - .190 DIA X .438 U1653 POST SBE75-0005 | ab-ad | 2 |
| 954 | AS41104 | • NUT - .190 DIA U1653 POST SBE75-0005 PRE SBE72-0329 | ab-ac | 2 |
| 954A | 4W0001 | • NUT - .190 DIA POST SBE72-0329 | ab-ad | 2 |
| - ITEM NOT ILLUSTRATED, ***** EFFECTIVITY NOT AVAILABLE | ||||
Figure: ELECT HARNESS-LIGHT DUTY-EEC LINK HARNESS-CORE
EEC LINK HARNESS CORE
