TASK 72-50-42-300-001 No. 5 Bearing Seal Rear Spacer - Lap The Contact Surfaces, Repair-001 (VRS3146)
General
Price and availability - refer to IAE
The practices and processes referred to in the procedure by the TASK numbers are in the SPM.
Preliminary Requirements
Pre-Conditions
NONESupport Equipment
NONEConsumables, Materials and Expendables
NONESpares
NONESafety Requirements
NONEProcedure
Refer to: Figure
Refer to the SPM TASK 70-11-18-300-503.
The seal thickness of 0.752 to 0.756in. (19.101 to 19.202 mm) must be maintained.
Lap the face of the seal.
SUBTASK 72-50-42-350-051 Lap the Face of the No. 5 Bearing Face Seal
Refer to: Figure
Refer to TASK 72-50-42-200-000 (INSPECTION/CHECK-000).
Examine the seal after repair.
SUBTASK 72-50-42-220-080 Examine the Repair
Figure: Lap the No. 5 bearing face seal
Lap the No. 5 bearing face seal
