TASK 72-60-40-200-001 Angle Gearbox Assembly - Examine The Oil Nozzles, Inspection-001

DMC:V2500-A0-72-60-4000-00A-300A-C|Issue No:001.00|Issue Date:2013-11-01

Export Control

EAR Export Classification: Not subject to the EAR per 15 C.F.R. Chapter 1, Part 734.3(b)(3), except for the following Service Bulletins which are currently published as EAR Export Classification 9E991: SBE70-0992, SBE72-0483, SBE72-0580, SBE72-0588, SBE72-0640, SBE73-0209, SBE80-0024 and SBE80-0025.

Copyright

© IAE International Aero Engines AG (2001, 2014 - 2021) The information contained in this document is the property of © IAE International Aero Engines AG and may not be copied or used for any purpose other than that for which it is supplied without the express written authority of © IAE International Aero Engines AG. (This does not preclude use by engine and aircraft operators for normal instructional, maintenance or overhaul purposes.).

Applicability

All

Common Information

TASK 72-60-40-200-001 Angle Gearbox Assembly - Examine The Oil Nozzles, Inspection-001

Effectivity

FIG/ITEM

PART NO.

01-240

4B0252

01-400

4B0241

General

This TASK gives the procedure for the inspection of the oil nozzles. For other parts of the main gearbox assembly refer to TASK 72-60-40-200-000 (INSPECTION-000).

Fig/item numbers in parentheses in the procedure agree with those used in the IPC.

The policy that is necessary for inspection is given in the SPM TASK 70-20-00-200-501.

All the parts must be cleaned before any part is examined. Refer to the TASK 72-60-40-100-000 (CLEANING-000).

All parts must be visually examined for damage, corrosion and wear. Any defects that are not identified in the procedure must be referred to IAE.

The procedure for those parts which must have crack test is given in SUBTASK 72-60-30-230-051

Do the test before the part is visually examined. Limits for cracks are given in the SUBTASK for each part.

A ** following repair referenced in this inspection indicates that the repair is not yet published in the current revision of the manual and the part must be rejected. Contact IAE for additional information concerning FAA approved repair date.

Do not discard any part until you are sure there are no repairs available. Refer to the instructions in repair before a discarded part is used again or oversized parts are installed.

Parts which should be discarded can be held although no repair is available. The repair of a discarded part could be shown to be necessary at a later date.

All parts must be examined to make sure that all the repairs have been completed satisfactorily.

The practices and processes referred to in the procedure by the TASK numbers are in the SPM.

Reference

Refer to the SPM for data on these items

Definitions of Damage, TASK 70-02-02-350-501 and TASK 70-02-00-350-501

Record and Control the lives of Parts, TASK 70-05-00-220-501

Inspection of Parts, TASK 70-20-00-200-501

Some data on these items is contained in this TASK. For more data on these items refer to SPM.

Method of Testing for Crack Indications

Chemical Processes

Surface protection

NOTE

Consumable materials are given in the SPM.

Preliminary Requirements

Pre-Conditions

NONE

Support Equipment

NameManufacturerPart Number / IdentificationQuantityRemark
FPI Inspection stationLOCALFPI Inspection station

Consumables, Materials and Expendables

NONE

Spares

NONE

Safety Requirements

NONE

Procedure

    1. SUBTASK 72-60-40-230-051 Examine the Oil Nozzles (01-240 and 01-400) for Cracks

    1. Clean the parts. Refer to TASK 72-60-40-100-000 (CLEANING-000).

      2. Do the test for cracks on the parts that are given below. Use the applicable penetrant procedure.

        PART IDENT

        TASK/SUBTASK

        Oil Nozzles

        1. Cracked

        1. Reject

        2. Through porosity

        1. Reject

    2. SUBTASK 72-60-40-220-053 Examine the Oil Nozzles (01-240 and 01-400) Orifice at Location 1

    1. Refer to Figure.

      2. Restricted or distorted

      1. Reject

      3. Presence of contamination

      1. Reject

    3. SUBTASK 72-60-40-220-057 Examine the OIl Nozzles (01-240 and 01-400) Machined Seal Surface at Location 2

    1. Refer to Figure.

      2. Nicked, scored, dented or scratched

        1. All quantity, all length not more than 0.0039in. (0.10 mm) in depth not extended accross the surface

        1. Accept

        2. More than Step

        1. Reject

    4. SUBTASK 72-60-40-220-055 Examine the Oil Nozzles (01-240 and 01-400) All Remaining Area

      1. Nicked, scored, dented or scratched

        1. All quantity, all length, not more than 0.008 in. (0.20 mm) in depth

        1. Accept

        2. More than Step

        1. Reject

    5. SUBTASK 72-60-40-220-056 Examine the Oil Nozzles (01-240 and 01-400) Piloting Diameters at Locations 3 and 4

    1. Refer to Figure

      2. Larger diameter

        1. Between 0.787 and 0.783 in. (20.00 and 19.90 mm)

        1. Accept

        2. Less than 0.783 in. (19.90 mm)

        1. Reject

      3. Smaller diameter

        1. Between 0.549 and 0.545 in. (13.95 ans 13.85 mm)

        1. Accept

        2. Less than 0.545 in. (13.85 mm)

        1. Reject

    6. Figure: Locations - gerabox casing surfaces

    Locations - gerabox casing surfaces
